1. Instructions for using the heating method of the screw oil press
The screw oil press is a low-temperature oil pressing equipment. The heating temperature range is generally below 100℃, which is very helpful for ensuring the quality of the oil. The heating method of the screw oil press is electric heating tube heating, which is mainly divided into the following steps:
1. Turn on the heating switch on the control panel and turn on the machine;
2. Set the heating temperature, press the temperature adjustment key, and set the required heating temperature;
3. When the heating temperature reaches the set temperature, the heating lamp will go out;
4. During the oil pressing process, the heating switch needs to be adjusted as needed to keep the heating temperature stable.
Models |
MK60 |
MK1685 |
MK1688 |
MK120 |
MK50 |
Power |
Main engine |
2.0 kw |
3kw |
3.5 kw |
4kw |
Vacuum pump |
4x-3kw |
6x-5.5kw |
6x-7.5kw |
6x-11kw |
6x-30kw |
Heater |
2.0kw |
3kw |
3.5kw |
4kw |
5kw |
capacity |
40-50kg/h |
80-160kg/h |
150-260kg/h |
260-400kg/h |
450-550kg/h |
Whole weight |
270kg |
550kg |
760kg |
915kg |
1550kg |
Outside dimension |
1350*950*1170mm |
1700*1300*1600mm |
2000*1350*1750mm |
2050*1400*1800mm |
2450*1980*1770mm |
2. Do you have to press the switch all the time for heating?
For the heating requirements of the screw oil press, it is generally necessary to press the heating switch to start heating the equipment, and then automatically control the heating through the temperature controller. This can effectively save energy and ensure the stability and safety of heating.
Therefore, during the heating process, it is usually not necessary to press the heating switch manually all the time, but to set the temperature and let the oil press automatically keep heating, which can not only improve efficiency but also ensure safety.
III. Precautions
1. Before use, check whether the heating system of the oil press is normal;
2. During the heating process, do not touch the heating part of the oil press at will to avoid burns;
3. The heating temperature of the oil press should not exceed the set temperature, otherwise it will affect the quality of the oil;
4. If you want to stop heating, you must first turn off the heating switch and wait for the heating tube to cool down completely.
