1. Easy to operate, small in size, saving land, labor and energy consumption.
2. The chamber has large pressing force and high oil output.
3. Long-term continuous work brings better economic benefits to users.
4. Good quality, durable, using the most suitable materials, and carefully processed to ensure use for more than 10 years.
5. Consumable parts are removable.
6. The design of hot and cold extrusion chambers is different.
7. Multifunctional combined automatic temperature control and oil vacuum filter.
8. Bevel gear technology, good operating performance.
Models |
MK60 |
MK1685 |
MK1688 |
MK120 |
MK50 |
Power |
Main engine |
2.0 kw |
3kw |
3.5 kw |
4kw |
Vacuum pump |
4x-3kw |
6x-5.5kw |
6x-7.5kw |
6x-11kw |
6x-30kw |
Heater |
2.0kw |
3kw |
3.5kw |
4kw |
5kw |
capacity |
40-50kg/h |
80-160kg/h |
150-260kg/h |
260-400kg/h |
450-550kg/h |
Whole weight |
270kg |
550kg |
760kg |
915kg |
1550kg |
Outside dimension |
1350*950*1170mm |
1700*1300*1600mm |
2000*1350*1750mm |
2050*1400*1800mm |
2450*1980*1770mm |
1. Driven by a triangle belt, the motor drives the spiral shaft.
2. The oil falls into the first section of the screw through the feeding part, and is transported to the end of the machine with the rotating extrusion screw.
3. As the gap between the pressing screws becomes smaller and smaller, friction will occur between the oil pressing devices and between the pressing screws and the pressing ring. The pressure is mounting.
4. During this process, the oil is crushed, a large amount of heat is generated, tissue cells are destroyed, and the oil is separated from the oil and flows out from multiple outlets.
5. The squeezed oil becomes a cake with low oil content and is cut into thin slices and discharged from the tail of the machine. The entire oil residue separation process is completed.
